Semi Automatic Volumetric Filling Machine

Semi Automatic Volumetric Filling Machine


Pneumatic piston filler for liquids and pastes. Multiple cylinder ranges from 5–100 ml up to 1000–5000 ml; dual nozzles with anti‑drip deliver ≈10–50 bpm.


View Specs Configure & Quote

  • Multiple volume modules
  • Dual nozzles
  • Two modes
  • Air & electric
Semi automatic pneumatic piston pump liquid & paste filler

Key Features

Multiple volume modules

5–100 / 10–300 / 50–500 / 100–1000 / 500–3000 / 1000–5000 ml.

Dual nozzles

Independent speed control; anti‑drip tips.

Two modes

Manual & auto with pedal test.

Air & electric

Requires 0.4–0.6 MPa and standard mains.

±0.5% accuracy

Cylinder scale and fine adjustment knob.

Hopper or hose feed

Swap to hose for liquids only.

Technical Specifications

Filling System

Model
LUGY2
Filling ranges
5–100 to 1000–5000 ml (modules)
Speed
≈10–50 bottles/min
Accuracy
≈±0.5%
Air pressure
0.4–0.6 MPa; >30 L air capacity
Driven type
Electric + pneumatic

Utilities & Dimensions

Voltage
110/220 V, 50–60 Hz
Power
≈10 W
Machine size
≈800 × 440 × 880 mm
Package size
≈960 × 515 × 330 mm (machine)
Hopper package
≈440 × 460 × 540 mm
Net/Gross weight
≈39 kg / 48 kg (approx.)

Performance depends on product, container, and setup. Ask us for a timed trial.

Typical Applications

Food

Sauces, jam, honey, chocolate.

Cosmetics

Shampoo, gels, creams.

Chemicals

Detergents and household products.

What’s Included

  • Base unit with two piston cylinders
  • Two filling nozzles with anti‑drip
  • Foot pedal and air prep unit
  • User manual

Configure Your Machine


Tell us about your application. We’ll confirm compatibility and quote the best configuration.

  • Product viscosity and solids content
  • Target volume and cycle speed
  • Nozzle size and neck finish
  • Air compressor capacity and utilities

Enquire now
