Large Continuous Band Sealer

High‑efficiency continuous foil induction sealing for larger formats. Digital controls with adjustable head and conveyor deliver airtight, tamper‑evident seals.

View Specs Configure & Quote

Non‑contact electromagnetic induction sealing
Adjustable head height & bottle inlet
0–10 m/min conveyor; 20–50 bpm (approx.)
Seal diameter Ø15–85 mm; bottle height 10–350 mm

Key Features

Induction heating ensures rapid, non‑contact seals

Independent temperature adjustment on control panel

Stable stainless conveyor for steady transport

Wide handling range—multiple cap diameters/heights

Compact machine with reasonable power draw (2.2 kW)

Easy setup for different formats

Technical Specifications

Key Parameters

Model: LUFK2200B
Voltage: 110 / 220 V, 50–60 Hz
Power: 2200 W
Sealing Diameter: Ø15–85 mm
Bottle Height: 10–350 mm

Additional Data

Conveyor Speed: 0–10 m/min
Sealing Speed: 20–50 bottles/min
Machine Weight: ≈ 25 kg
Package Size / Weight: 1000×585×550 mm / ≈ 49 kg

Typical Applications

Food & Beverage

Foil sealing of sauces, condiments, and drinks

Cosmetics & Personal Care

Tamper‑evident closure for creams and liquids

Chemicals

Secure sealing to reduce leakage and evaporation

What’s Included

Main machine with control panel
Conveyor/fixtures as pictured (where applicable)
Operator manual
Basic spare kit (where applicable)

Configure Your Large Continuous Band Sealer

Tell us about your products and line requirements. We’ll confirm compatibility and quote the best configuration.

Product & package dimensions
Target throughput (units/min)
Utilities available (power, air) & line height
Any coding/inspection you need inline

Large Continuous Band Sealing Machine
