Handheld Screw Capper

Handheld Screw Capper


Portable electric capper with adjustable clutch for 10–50 mm caps. Ideal for startups, rework stations, and low‑volume production.


View Specs Configure & Quote

  • Adjustable clutch
  • Fast & versatile
  • High‑torque motor
  • Lightweight
Handheld electric screw capper

Key Features

Adjustable clutch

Stops automatically when the target torque is reached.

Fast & versatile

Typical 30–90 bottles/min with chucks for 10–50 mm caps.

High‑torque motor

160 W model options for demanding caps and security rings.

Lightweight

Around 1.6 kg; easy to handle across shifts.

Complete kit

Includes multiple rubber pads/chucks and spring balance.

Dual voltage

110/220 V variants for global use.

Technical Specifications

Capabilities

Cap diameter
10–50 mm (kits include 28–32 and 38 mm rings)
Throughput
≈30–90 bottles/min (operator‑dependent)
Torque control
Clutch‑limited, adjustable speed
Applications
Plastic/metal screw caps, sprays, droppers
Stop function
Chuck stops rotating when tight
Kit contents
Chucks & rubber pads for common sizes

Electrical & Physical

Voltage
AC 110/220 V
Power
up to 160 W variants
Weight
≈1.6 kg (hand unit)
Accessories
Spring balance, hex wrench
Operator mode
Handheld, single‑operator
Safety
Use appropriate PPE and torque checks

Performance depends on bottle, cap, and setup. Ask us for a timed trial.

Typical Applications

Startups & labs

Economical solution for small batches.

Rework & QA

Retorquing and sampling tasks.

Mobile lines

Use at multiple stations across the plant.

What’s Included

  • Handheld capper
  • Assorted chucks & rubber pads
  • Spring balance
  • User manual

Configure Your Machine


Tell us about your bottles and closures. We’ll confirm compatibility and quote the best configuration.

  • Cap diameters and thread types
  • Target torque range / QC method
  • Bottle material and stability (fixtures if needed)
  • Power supply at workstation

Enquire now
